Camera Type | Color Standard Camera | ||
Image Sensor | 1/3 Inch SONY Hi-Res. CCD | 1/3 Inch SONY SuperHAD CCD | |
Effective Pixels | PAL:752(H) x582(V) 440K NTSC:768(H) x494(V) 380K |
PAL:500(H) x 582(V) NTSC:510(H) x 492(V) | |
Sensing Area | 4.9mm x 3.7mm | ||
Signal System | PAL /NTSC | ||
Horizontal Resolution | 520 TV Lines | 480 TV Lines | 420 TV Lines |
Min. Illumination | 0.3 Lux/F1.2 | 0.4 Lux/F1.2 | 0.5 Lux/F1.2 |
Lens Mount | CS/C Mount(C Mount adaptor optional) | ||
Iris Control | DC/VIDEO | ||
S/N Ratio | More Than 48dB (AGC Off) | ||
Electronic Shutter | 1/50(1/60) ~ 1/10,000 Sec. | ||
White Balance | Auto | ||
AGC | ON/OFF switchable | ||
BLC | ON/OFF switchable | ||
I/O Connector | Power : 2 Pin Terminal, Video Output : BNC ,Audio Output:RCA | ||
Video Output Level | 1.0 Vp-p (75 Ohms, composite) | ||
Audio Output Level | 2.0Vp-p Max | ||
Supplied Voltage | DC12V Voltage | ||
Power Consumption | Less than 130mA | ||
Dimensions | 49 x 68 x 119mm | ||
Weight | Approx. 0.5kg |
